KH10-3H-120-02

KH10-3H-120-02 are small aluminum compatible connectors that provide tight and compact connections in DC, capacitive and hybrid circuits. Due to their design, they allow reliable soldering of aluminum and other materials with a high coefficient of expansion, designed for extreme temperature conditions. Durable pins allow you to attach or wire or tape to sides or ends.

Specifications:

Characteristic impedance	50 Ohm
Fabrication	Outside shell and the inner conductor of the shell is made of Kovar alloy, gold plated surface treatment. The insulating medium is made of glass
Standart	GJB976A-2009
Temperature	-55° ± 125°
Salt spray	48h
Voltage	Medium withstand voltage 500V, Insulation resistance ≥ 1000 Mohm
Leak tightness	Air tightness test requirements do not exceed 1.013x10-3 Pa.cm3 /s
